一、功能用途
同时测量磁导率与磁场强度,主要应用于汽车,医疗,石油天然气,铸造,航空航天,环保,地质等领域.
二、性能参数
磁导率范围: 1.00001 - 2 ur
磁场强度范围: 0.1 nano 特斯拉 to 1 milli 特斯拉(0.1 nT- 1 mT)
配合磁场探头和梯度探头,磁场强度灵敏度可高达:0.1 毫微特斯拉
磁导率测量测量结果可按照国家标准跟踪
采用比较法,测量工件的磁导率,从而检测出材料的变化
单位可选: 特斯拉 高斯 奥斯特 安匝/米
符合 CE人证,PTB跟踪报告
Determination of the magnetic moment of a dipole
Measurement of the demagnetized state of a material
Verification of non-magnetic properties in critical components
Detection of internal sulfidation distress in aircraft turbine blades
Features
Wide range of sensors for various measurement tasks
Battery operation for portable use or AC operation for use in the
laboratory
Automatic probe recognition and calibration
Automatic field compensation to eliminate the influence of ambient
fields
Selectable measurement units for magnetic field strength measurement
Remote control via RS 232 interface
Traceable calibration standards for magnetic permeability measurement
Data storage and transfer via compact flash card
Selectable display modes on ? VGA display with back light
User configurable reject limits with audible or visual alarm indications
Analog output available from BNC connection
Multi-lingual operator interface
Available Probes
Foerster offers a broad range of probes for field and permeability
measurement with the MAGNETOSCOP 1.069
|
MAGNETOSCOP 1.069
便携式磁导率与磁场强度测量仪
点击下载PDF.英文资料
|
